Fig. 498: Speed Sensors
Courtesy of CHRYSLER LLC
1. Unplug the electrical connector at the transfer shaft sensor (3).
Fig. 499: Speed Sensor O
-Ring
Courtesy of CHRYSLER LLC
2. Remove the bolt at transfer shaft sensor (1).
3. Pull up on transfer shaft sensor to remove.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
