transaxle case.
OPERATION
OPERATION
Fig. 497: Speed Sensors
Courtesy of CHRYSLER LLC
The transfer shaft speed sensor (3) is located at the rear of the case (backside). It reads rotation of the front
annulus/rear carrier assembly.
REMOVAL
REMOVAL
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
