Fig. 587: Valve Body Bolts
Courtesy of CHRYSLER LLC
19. Remove the twenty one valve body to case bolts (1).
Fig. 588: Oil Transfer Tubes
Courtesy of CHRYSLER LLC
20. Insure the manual lever is fully forward to keep the manual valve pin (3) from binding.
21. Pull the valve bod
y
awa
y
from the underdrive compounder assembl
y
oil transfer tubes (2) and lift up on
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
