7. Install Disk 6057 (1), Compressor 5059-A (2) and Compressor Bar 5058A-3 (3).
Fig. 120: Spring Compressor 5059-A
Courtesy of CHRYSLER LLC
8. Install low/reverse spring compressor into position.
Fig. 121: Snap Ring
Courtesy of CHRYSLER LLC
3 - COMPRESSOR BAR 5058A-3
1 - LOW/REVERSE CLUTCH RETURN SPRING
2 - SNAP RING (INSTALL AS SHOWN IN
ILLUSTRATION)
3 - DISC 6057
4 - COMPRESSOR 5059
5 - COMPRESSOR BAR 5058-3
