9. Compress low/reverse piston and install snap ring (1).
Fig. 122: Rear Carrier Bearing Cone
Courtesy of CHRYSLER LLC
10. Install rear carrier bearin
Installer 6053 (1).
1 - SNAP RING OPENING MUST BE BETWEEN SPRING
LEVERS (AS SHOWN IN ILLUSTRATION)
2 - SNAP RING PLIERS
3 - DISC 6057
1 - ARBOR PRESS RAM
2 - INSTALLER 6053
3 - NEW BEARING CONE
4 - REAR CARRIER ASSEMBLY
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
