Fig. 123: Rear Carrier
Courtesy of CHRYSLER LLC
11. Install rear carrier assembly (1) to transaxle case.
Fig. 124: Output Gear Bearing Cone
Courtesy of CHRYSLER LLC
12. Install output gear bearing cone using Installer 6758 (3).
1 - ARBOR PRESS RAM
2 - HANDLE C-4171
3 - INSTALLER 5052
4 - OUTPUT GEAR
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:08 PM Page 79 © 2006 Mitchell Repair Information Company, LLC.
