28. Install 2/4 clutch retainer to transaxle (1, 2).
Fig. 137: 2/4 Clutch Retainer Snap Ring
Courtesy of CHRYSLER LLC
29. Using Compressing Tool 5058A (1), compress 2/4 clutch return spring just enough to install snap ring
(3).
30. Install snap ring.
Fig. 138: Check 2/4 Clutch Clearance
2 - 2/4 CLUTCH RETURN SPRING
1 - COMPRESSING TOOL 5058A
2 - SCREWDRIVER
3 - SNAP RING
4 - 2/4 CLUTCH RETAINER
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
