Cisco ASR 1002 Hardware Installation Guide

DescriptionColorLEDLED Label
LED illuminates green to signal
that voltage is > or = to 20VDC
at turn-on and down to
19.0VDC (+/- 0.5 V tolerance).
GreenA bi-color LED indicates
presence of input voltage
INPUT OK
The LED illuminates amber
when the input voltage is active
down to 16.0VDC and indicates
that there is still a voltage
present (voltage on the terminal
block). The LED remains amber
and is active to around 10 V.
The LED can be OFF below
15.8VDC.
Amber
The LED illuminates s green
when all fans are operational.
GreenA bi-color LED indicates power
supply fan status
FAN OK
The LED illuminates red when
a fan failure is detected.
Red
+24 VDC Power System Input for Cisco ASR 1002 Router
The +24 VDC power supply operates within specification between +21 and +36 VDC continuously once the
power supply DC input is turned on. The power supply shall measure the input voltage at the terminals of the
power supply and turn off the supply when the input voltage reaches 19.0 volts +/- 0.5 volts. Once this low
voltage threshold is reached, the power supply does not resume operation until the input voltage has reached
20.0 volts +/- 0.5 volts. Once the turn-on threshold of 20 volts is reached, then the +24 VDC power supply
meets all specification requirements down to low voltage threshold of 19 volts (+/- tolerance).
+24 VDC Power System Output for Cisco ASR 1002 Router
The +24 VDC power supply output tolerance is defined in the following table under all combinations of +24
VDC input line variation. Total system power consumption should not exceed 470 watts or output rating of
each power supply.
Two power supplies are used for redundant operation. System total power consumption shall never exceed
rating of one power supply to maintain redundancy.
Note
Table 30: Cisco ASR 1002 Router +24 VDC Power System Output Voltage and Current
+3.3 V+12 VDCOutput Voltage
3.2011.80Minimum
Cisco ASR 1000 Series Router Hardware Installation Guide
74
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1002 Router +24 VDC Power Supply

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
