Cisco ASR 1002 Hardware Installation Guide

Removing and Replacing Cisco ASR 1000 Series Route
Processors
Keep in mind the following points before you remove and replace a Cisco ASR 1000 Series route processor:
•
The Cisco ASR 1002 Router and the Cisco ASR 1002-F Router support only the integrated Cisco
ASR1002-RP1.
•
If you have two Cisco ASR 1000 Series route processors in the Cisco ASR 1006 or Cisco ASR 1013
router and you want to remove one, do not power down the router. Remove the route processor and
insert a new one because high availability provides for the other route processor to take on the processing
tasks for the router.
•
The Cisco ASR 1001 Router and the Cisco ASR 1002-X Router support an integrated route processor,
embedded services processor, and SIP.
The following sections describe the procedures for removing and replacing the Cisco ASR 1000 Series RP1
and Cisco ASR1000-RP2 in your Cisco ASR 1000 chassis. This section contains these topics:
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to any card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Removing the Cisco ASR 1000 Series Route Processor from the Cisco ASR
1006, Cisco ASR 1004, and Cisco ASR 1013 Routers
To remove the Cisco ASR 1000 Series route processor (RP1 or RP2) from the Cisco ASR 1006 Router, Cisco
ASR 1004 Router and Cisco ASR 1013 Router, follow this procedure:
SUMMARY STEPS
1.
Slip on an ESD-preventive wrist strap and attach it to a chassis surface.
2.
If connected, remove any I/O cables from the Cisco ASR 1000 Series route processor.
3.
Using a number 2 Phillips or a 3/16-inch flat-blade screwdriver, loosen the two captive screws on the
faceplate of the Cisco ASR 1000 Series route processor.
4.
Using the handles on both sides of the module, with two hands gently slide the module out of the chassis
slot.
5.
Place the Cisco ASR 1000 Series route processor module on an antistatic surface with its printed circuit
board components facing upward or in a static shielding bag.
Cisco ASR 1000 Series Router Hardware Installation Guide
474
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Route Processors

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
