Cisco ASR 1002 Hardware Installation Guide

SUMMARY STEPS
1.
Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component is
keyed for easy insertion.
2.
Tighten the fastener screw on the front panel.
3.
Wait until the following console message is displayed:
4.
Verify the disk is working by running: dir harddisk
DETAILED STEPS
Step 1
Carefully slide the internal hard drive unit into the Cisco ASR1000-RP2 faceplate slot. The component is keyed for easy
insertion.
Step 2
Tighten the fastener screw on the front panel.
Step 3
Wait until the following console message is displayed:
Example:
%IOSXE-0-PLATFORM: R0/0: udev: harddisk: file system ready” appears.
If, after several minutes, the above message is not displayed, run:
request platform hardware filesystem harddisk: online
The only reason the system would not be able to automatically mount the new hard disk following a physical
insertion is if the disk is not partitioned correctly.
Note
Step 4
Verify the disk is working by running: dir harddisk
What to Do Next
You have completed the steps required to replace the Cisco ASR1000-RP2 internal hard drive.
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X
Router
The Cisco ASR 1002-X Router supports an optional removable hard drive. This section explains how to
remove and replace this hard drive.
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
•
The hard drive is accessible from the front panel of the router and supports the online insertion and
removal feature (OIR) using the following CLI commands:
◦
request platform hardware filesystem harddisk: offline (unmounts the hard disk)
◦
request platform hardware filesystem harddisk: online (mounts the hard disk.)
Cisco ASR 1000 Series Router Hardware Installation Guide
487
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Hard Drive on the Cisco ASR 1002-X Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
