Cisco ASR 1004 Router Memory and Storage Options
The following table lists the hardware memory and storage options supported on the Cisco ASR 1004 Router.
Table 104: Memory and Storage Options for Cisco ASR 1004 Router
Maximum System SupportDefaultMemory Type
4 GBDRAM2 GB DRAMRP1
For mass storage: hard disk drive 40 GB
or solid-state drive 32Gb support
1 GB (Partitioned: 2x32MB for NVRAM
and the remaining for mass storage
eUSB
Cisco ASR 1004 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1004 Router has RJ-45 port for the 10/100/1000 Ethernet connection. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially. See xref Figure A-1
to see an RJ-45 port and connector.
Cisco ASR 1004 Router MGMT Ethernet Port Signals and Pinouts
The following table lists the RJ-45 port pinouts for the front panel Management Ethernet port.
Table 105: RJ-45 Management Ethernet Port Pinouts for the Cisco ASR 1004 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
622
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Memory and Storage Options

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
