Cisco ASR 1002 Hardware Installation Guide

DescriptionPower Cord Item Number
Power Cord Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord UK, Right AngleCAB-ACU-RA
Power Cord India, Right AngleCAB-IND-RA
Power Cord-Japan, Right AngleCAB-JPN-RA
Installation Methods
Cisco ASR 1001 Router is designed for standalone, two rail 19-inch rack-mount (front rail only), four rail
19-inch rack-mount (front and rear rail).
Although rack-mounting is the preferred method of installation for the Cisco ASR 1001 Router, you can
mount the chassis on an equipment shelf or tabletop.
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each warning
to locate its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information
for Cisco ASR 1000 Series Aggregation Services Routers publication. This document provides important
safety information you should know before working with the system. Statement 200
Warning
You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
•
The Cisco ASR 1001 Router requires a minimum of 3.5 inches or 8.9 cm rack units of vertical rack
space. Measure the proposed rack location before mounting the chassis in the rack.
•
Before using a particular rack, check for obstructions (such as a power strip) that could impair rack-mount
installation. If a power strip does impair a rack-mount installation, remove the power strip before installing
the chassis, and then replace it after the chassis is installed.
Cisco ASR 1000 Series Router Hardware Installation Guide
425
Cisco ASR 1001 Router Overview and Installation
Installation Methods

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
