Cisco ASR 1002 Hardware Installation Guide

AWG # WireCircuit Breaker
Amps
System Input
Rating (Amps)
Cisco ASR 1000
Series Router
DC Power
Supply
Cisco ASR
1002-X:
• –48 VDC
•
+24 VDC
1012302016
88404032
For example, the
Cisco ASR 1002
Router DC
power supply,
with 16 Amp
input rating
must use an
AWG #12 gauge
wire for a 20 A
circuit breaker
and an AWG
#10 gauge wire
for a 30 A
circuit breaker.
All Cisco ASR 1000 Series Router AC power supplies must be connected to a branch circuit that does
not exceed 20 A.
Note
AC and DC Power Supply Types
The AC and DC power supplies for the Cisco ASR 1000 Series Routers support different types of power
supply switches. The following table defines which power supplies the Cisco ASR 1000 Series routers support
(a standby or an On/Off switch).
Table 15: Cisco ASR 1000 Series Routers AC and DC Power Supply Switches
Cisco ASR 1000 Series Router
Power Supply
SymbolSwitch Type Supported
ASR 1006 –48 VDC
ASR 1004 –48 VDC
ASR 1002 AC
ASR 1002-X AC
I/OOn/Off circuit
Cisco ASR 1000 Series Router Hardware Installation Guide
50
Cisco ASR 1000 Series Routers Component Overview
AC and DC Power Supply Types

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
