Cisco ASR 1002 Hardware Installation Guide

ASR 1013ASR 1006ASR 1004ASR 1002-XASR 1002ASR 1002-FASR 1001Component
—
Single or
Dual
ASR1000-RP1
Single
ASR1000-RP1
Single
integrated
route
processor
Single
integrated
ASR1000-RP1
Single
integrated
ASR1000-RP1
Single
integrated
route
processor
Route
Processor
Single or
Dual
ASR1000-RP2
Single or
Dual
ASR1000-RP2
Single
ASR1000-RP2
———
ASR1000-SIP10ASR1000-SIP10ASR1000-SIP10Integrated
SIP
Integrated
SIP
Integrated
SIP
Integrated
SIP
SIP
ASR1000-SIP40ASR1000-SIP40ASR1000-SIP40
——
241283 HH SPA
bays
311
half-height
(HH) SPA
bay
SPA Slots
Cisco ASR 1000 Series Hardware Configuration Combinations
This section provides Cisco ASR 1000 Series hardware configuration combinations and whether they are
supported from Cisco IOS XE Release 3.1S onward. The tables list the router and the route processor, SIPs,
and power modules supported on that router. The tables include the following categories
• Supported hardware before IOS XE Release 3.1S—xref table
• Supported hardware from IOS XE Release 3.1S—xref table
• Requires upgrade—xref table
• Not compatible—xref table
• Not supported in IOS XE Release 3.1S—xref table
• Incompatible HA—xref table
When an unsupported combination of hardware components occurs, the card or cards not supported are
shutdown and an error message occurs. Following each table in this section, a description of the error
message is provided.To prevent any errors from occurring, read the compatibility tables before you insert
any Cisco ASR 1000 Series Router components on a router running Cisco IOS XE Release 3.1S or later
releases.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
29
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Hardware Configuration Combinations

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
