Cisco ASR 1002 Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1004 Router Specifications
This section lists the specifications for the Cisco ASR 1004 Router.
The following table lists the Cisco ASR 1004 Router physical specifications.
Table 103: Cisco ASR 1004 Router Specifications
SpecificationDescription
Connects the Cisco ASR 1000 Series RP1, ASR 1000 Series ESP,
Cisco ASR 1000 Series SPA Interface (SIP), SPAs, and power
supplies together in the system
Midplane
Height = 7 in. (17.8 cm) (4RU rack-mount per EIA RS-310)
Width = 17.25 in. (43.815 cm) (19 inch rack-mount or optional
23 Telco rack- mount)
Depth = 22.50 in. (57.15 cm) (including card handles,
cable-management brackets and power supply handles)
Dimensions (H x W x D)
•
Fully loaded chassis: 50 pounds (22.6796 kg)
•
Only chassis: 18 pounds (8.16 kg)
Weight
•
41° to 104° F
•
5° to 40° C
Nominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum DC: 1020W
•
Maximum AC: 960W
•
Maximum (Out): 765W
Power consumption
Cisco ASR 1000 Series Router Hardware Installation Guide
621
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Specifications

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
