Cisco ASR 1002 Hardware Installation Guide

Upgrading to New Software
For a listing of the new SPAs, click the corresponding link in the table.Note
Table 5: Cisco ASR 1000 Series Router Component Software Support
Cisco Hardware ComponentsCisco IOS XE Software Support
•
Cisco ASR 1002 Router
•
Cisco ASR 1004 Router
•
Cisco ASR 1006 Router
•
Cisco ASR 1000 Embedded Services Processors
•
Cisco ASR 1000 Route Processor 1
•
Cisco ASR 1000 SPA Interface Processor
•
Shared Port Adapters
•
1 GB USB Flash Token for Cisco ASR 1000
Series
Cisco IOS XE Release 2.1.0
•
Cisco ASR 1000 Embedded Services Processor
10G Non Crypto Capable (ASR1000-ESP10-N)
•
Cisco ASR1000-ESP20 embedded services
processor
Cisco IOS XE Release 2.2.1
•
Shared Port Adapters
•
Cisco ASR 1000 Series Route Processor 2
(Cisco ASR1000-RP2)
Cisco IOS XE Release 2.3.0
•
Shared Port Adapters
•
Cisco ASR 1002-F Router
Cisco IOS XE Release 2.4.0
•
WebEx SPA
Cisco ASR 1000 Series Router Hardware Installation Guide
26
Cisco ASR 1000 Series Routers Component Overview
Upgrading to New Software

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
