Cisco ASR 1002 Hardware Installation Guide

Hardware Requiring a CPLD Upgrade
For details about Cisco ASR 1000 hardware configuration combinations that require a CPLD field
programmable upgrade for components to be supported in IOS XE Release 3.1S, see Upgrading Field
Programmable Hardware Devices for Cisco ASR 1000 Series Routers .
Incompatible Hardware Configuration Combinations
The following table lists ASR 1000 hardware configuration combinations that are not compatible from Cisco
IOS XE Release 3.1S onward.
Table 7: Incompatible Cisco Hardware Configuration Combinations from IOS XE Release 3.1S Onward
ResultASR1000-SIPASR1000-ESPASR1000-RPChassis
ESP-20 disabled
ESP-40 disabled
ESP-100 disabled
NA (built in)ESP-20
ESP-40
ESP-100
NA (built in)Cisco ASR 1002
Router
ESP-5 disabled
ESP-100 disabled
—
ESP-5
ESP-100
—
Cisco ASR 1004
Router
ESP-5 disabled
—
ESP-5
—
Cisco ASR 1006
Router
RP1 disabled
——
RP1Cisco ASR 1013
Router
—
NA (built in)Integrated
embedded services
processor
NA (built in)Cisco ASR 1001
Router
—
NA (built in)Integrated
embedded services
processor
NA (built in)Cisco ASR 1002-X
Router
Incompatible ASR1000-ESP Error Message
This section describes what happens when an incompatible Cisco ASR1000-ESP is inserted into the following
Cisco ASR 1000 series router:
•
Cisco ASR1000-ESP20 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP40 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP100 is inserted into Cisco ASR 1002 Router
•
Cisco ASR1000-ESP5 or Cisco ASR1000-ESP100 is inserted into Cisco ASR 1004 Router or ASR 1006
Router
Cisco ASR 1000 Series Router Hardware Installation Guide
30
Cisco ASR 1000 Series Routers Component Overview
Cisco ASR 1000 Series Hardware Configuration Combinations

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
