Cisco ASR 1002 Hardware Installation Guide

Management Ethernet Port Cable Connection
To comply with Class A emissions requirements, a shielded Ethernet cable must be used for the connection.Caution
To use the Management Ethernet interface on the router, perform the following steps:
SUMMARY STEPS
1.
Insert an Ethernet RJ-45 cable into the MGMT ETHERNET port (see “Common Connectors for Cisco
ASR 1001 Route Processor” figure in the Cisco ASR 1001 Router Faceplate Common Components section).
2.
Insert the other end of the RJ-45 cable to your management device or network.
DETAILED STEPS
Step 1
Insert an Ethernet RJ-45 cable into the MGMT ETHERNET port (see “Common Connectors for Cisco ASR 1001 Route
Processor” figure in the Cisco ASR 1001 Router Faceplate Common Components section).
Step 2
Insert the other end of the RJ-45 cable to your management device or network.
Connecting a Terminal to the Cisco ASR1000-RP1 Console Port
The Cisco ASR 1001 embedded route processor has an asynchronous serial (EIA/TIA-232) RJ-45 console
port labeled CON on its front panel. You can connect this port to most types of video terminals through use
of the console cable kit that is included with your Cisco ASR 1001 Router. The console cable kit contains:
•
One RJ-45 to RJ-45 crossover cable
•
One RJ-45 to DB-25 (female) adapter
•
One RJ-45 to DB-9 (female) adapter
A crossover cable reverses pin connections from one end to the other. In other words, it connects pin 1 (at
one end) to pin 8 (at the other end), pin 2 to pin 7, pin 3 to pin 6, and so on. You can identify a crossover cable
by comparing the two modular ends of the cable. Hold the cable ends in your hand, side-by-side, with the
tabs at the back. Ensure that the wire connected to the outside (left) pin of the left plug (pin 1) is the same
color as the wire connected to the outside (right) pin of the right plug (pin 8).
Use the following procedure to connect a video terminal to the console port on a route processor.
Each Cisco ASR 1000 Series Route Processor must have a console port connection (typically to a terminal
server) if you are running a redundant configuration in the chassis.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
442
Cisco ASR 1001 Router Overview and Installation
Management Ethernet Port Cable Connection

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
