Cisco ASR 1002 Hardware Installation Guide

Step 3
Turn off the branch circuit breaker before touching terminal screws. Then start loosening the terminal block screws to
remove wires.
Step 4
Remove the leads from the terminal block in the following order.
a) Negative lead
b) Positive lead
c) Ground lead
Step 5
Unscrew all of the power supply captive screws.
Two power supplies must be installed in the chassis at all times, with a minimum of one power supply connected
to the mains in order to power on the system and ensure sufficient cooling. The system fans are inside the power
supply units and must spin for cooling. Because all the system fans can be powered by one power supply, the
second power supply unit does not have to be powered on, but must be connected.
Note
If you remove a power supply from a system that are connected and powered on, the system can run only for
a maximum of five minutes before shutting down. However, because the fans and power elements are
independent within the power supply, the replacement power supply does not have to be energized within
five minutes. The only requirement is that the power supply be installed in the chassis in order to energize
the fans and maintain proper system cooling.
Caution
Step 6
Grasping the power supply handles, pull the power supply from the chassis.
Step 7
Replace the –48 VDC power supply within five minutes.
What to Do Next
This completes the procedure of removing a –48 VDC power supply from the Cisco ASR 1002 Router.
Replacing the –48 VDC Power Supply in Cisco ASR 1002 Router
The –48 VDC power supply input connector is a Euro-style terminal block. Features are provide for strain
relieving the input wires from the terminal block on the front panel. The ground wire must contain a loop
when secured to prevent any strain on the wires. The connection order is negative (–), positive (+), and GND.
The recommended branch circuit breaker for the Cisco ASR 1002 Router –48 VDC power supply is 30 A.
Use an AWG #10 gauge wire on the 30 A circuit.
This section describes how to connect the –48 VDC power supply in the Cisco ASR 1002 Router.
The color coding of the –48 VDC input power supply leads depends on the color coding of the –48 VDC
power source at your site. Typically, green or green/yellow is used for ground. Make certain the lead color
coding you choose for the –48 VDC input power supply matches lead color coding used at the –48 VDC
power source.
Note
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Cisco ASR 1000 Series Router Hardware Installation Guide
573
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing a –48 VDC Power Supply in Cisco ASR 1002 Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
