Cisco ASR 1002 Hardware Installation Guide

1
The fan in each PEM receives power and begins drawing air through the power supply. The power supply
PWR OK indicator is on and reflects power supply status.
2
As the power on and boot process progresses for the Cisco ASR 1000 Series RPs, ASR 1000 ESPs, and
each installed SIP, the status of each card is indicated by LEDs. On routers that have an integrated route
processor, embedded services processor, and SIP, the status LED shows the status of the process.
Troubleshooting the Power Subsystem
Use the information in the following table to isolate problems with the power system.
Table 139: Troubleshooting the Power System
Possible SolutionPossible CauseSymptom
There is a power fault in the
chassis.
The status LED stays amber during
the entire boot process and then
turns green when the software has
completely booted.
System has failed to boot.System begins power on
Turn the router power switch to the
standby position (|) and reseat the
AC power cable at the system or at
the wall outlet (power source).
AC power cable not fully seated at
system or at the wall outlet (power
source).
System does not power on.
Turn the router power switch to the
standby position (|) and locate the
circuit breaker on the panel board
that services the DC circuit; switch
the circuit breaker to the on
position.
DC power cable not turned on at
the panel board of the circuit
breaker.
Turn the router power switch to the
standby position (|) and remove and
reinsert the power supply cable.
AC internal power cables are not
fully seated from the power supply
Cisco ASR 1000 Series Router Hardware Installation Guide
648
Troubleshooting Initial Startup Problems
Troubleshooting the Power Subsystem

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
