Cisco ASR 1002 Hardware Installation Guide

The embedded shared port adapter interface processor (SIP) on the Cisco ASR 1002 Router and Cisco
ASR 1002-F Router do not support online insertion and removal. However, the SPAs on the Cisco embedded
services processors do support online insertion and removal.
Note
When removing or replacing SPAs, make certain that all the screw fasteners on each card and each SIP
are screwed in tightly to prevent accidental removal of another card. Each SIP has two screw fasteners
per slot and each SPA has two screw fasteners.
Caution
We suggest you have the following tools and parts readily available for installation of the SIPs and SPAs:
•
Number 2 Phillips or a 3/16-inch flat-blade screwdriver
•
Shared port adapter interface processor (SIP)
•
Shared port adapters (SPAs)
•
Cables
•
Your own ESD-prevention equipment or the disposable grounding wrist strap included with all upgrade
kits, field-replaceable units (FRUs), and spares
•
Antistatic mat or surface, or static shielding bag
If you need additional equipment, contact a service representative for ordering information.
Electrostatic Discharge Prevention
Electrostatic discharge (ESD) damages equipment and impairs electrical circuitry. ESD occurs when printed
circuit boards are improperly handled and results in complete or intermittent failures.
Each SPA circuit board is mounted to a metal carrier and is sensitive to electrostatic discharge (ESD) damage.
The SIP and SPAs consist of a printed circuit board that is fixed in a metal carrier. Electromagnetic interference
(EMI) shielding, connectors, and a handle are integral components of the carrier.
When a subslot is not in use, a SPA blank filler plate must fill the empty subslot to allow the router to conform
to electromagnetic interference (EMI) emissions requirements and to allow proper airflow across the installed
modules. If you plan to install a SPA in a subslot that is not in use, you must first remove the SPA blank filler
plate.
Cisco ASR 1000 Series Router Hardware Installation Guide
534
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Electrostatic Discharge Prevention

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
