Cisco ASR 1002 Hardware Installation Guide

DETAILED STEPS
Step 1
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
Step 2
Tighten the captive screws.
Step 3
Insert the AC power cable into the power inlet.
Step 4
Plug the power supply cable into the power source.
For additional AC power cable strain relief, secure the cable to the power supply handle by inserting a nylon
cable tie through the hole in the handle and around the cable.
Note
Figure 73: Cisco ASR 1004 Router AC Power Supply, on page 211 shows the Cisco ASR 1004 Router AC power supply.
Figure 73: Cisco ASR 1004 Router AC Power Supply
AC power supply fan4AC power supply Standby
switch
1
AC power inlet5AC power supply LEDs2
AC power supply handle6DB-25 alarm connector3
Shielded cables must be used to connect to the DB-25 alarm connector on both the AC and –48 VDC power
supplies in order to comply with FCC/EN55022/CISPR22 Class A emissions requirements. See the “How Cisco
ASR1000-RP Alarm Monitoring Works” section on page 2-22 .
Note
Step 5
Turn the power supply switch to the On position.
What to Do Next
This completes the procedure for connecting AC input power.
Connecting --48 VDC Input Power to Cisco ASR 1004 Router
This section describes how to connect the –48 VDC power supply in the Cisco ASR 1004 Router.
Figure 74: Cisco ASR 1004 Router –48 VDC Power Supply , on page 211 shows the –48 VDC power supply.
Figure 74: Cisco ASR 1004 Router – 48 VDC Power Supply
–48 VDC power supply
ground symbol
5
–48 VDC power supply
terminal block and plastic
cover
1
Cisco ASR 1000 Series Router Hardware Installation Guide
211
Cisco ASR 1004 Router Overview and Installation
Connecting --48 VDC Input Power to Cisco ASR 1004 Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
