Cisco ASR 1002 Hardware Installation Guide

Table 136: Console Port Pinout for Cisco ASR1000-ESP100
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR1000-ESP200 Console Port Pinout Specifications
Cisco ASR1000-ESP200 provides a debug console on an 8-pin header. The following table lists the console
port pinouts for Cisco ASR1000-ESP200.
Table 137: Console Port Pinout for Cisco ASR1000-ESP200
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR 1000 Series Router Hardware Installation Guide
643
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Cisco ASR1000-ESP200 Console Port Pinout Specifications

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
