SPA slot 33
The Cisco ASR 1002-X Router has an integrated ESP which is not field upgradeable. Depending on the Cisco
optional software license that is installed, the ESP forwarding bandwidth can be software field upgraded from
the default bandwidth of 5 Gbps to 10 Gbps, 20 Gbps, or 36 Gbps. For more information about the software
license, see the Cisco ASR 1000 Series Aggregation Services Routers Release Notes at: http://www.cisco.com/
en/US/docs/routers/asr1000/release/notes/asr1k_rn_rel_notes.html
The following table describes the LEDs on the integrated ESP.
Table 69: Integrated ESP LEDs
Behavior in the
Power-Up State
ColorLEDLED LabelNo.
All the power supplies
are within operational
limits.
Solid greenPowerPWR1
Off. The router is in
standby mode.
Off
The ESP is green when
active.
GreenActiveACTV2
Code has successfully
downloaded, and is
operational.
GreenSTATUSSTAT3
Boot ROM has
successfully loaded.
Yellow
Not booted.Red
Will always be off.NoneStandbySTBY4
Power Supplies in the Cisco ASR 1002-X Router
The Cisco ASR 1002-X Router power supply module supports the following Cisco power supplies:
•
AC power supply operates between 85 V ac to 264 V ac
• –48 V DC power supply operates between –40.5 V dc and –72 V dc
•
+24 V DC power supply operates between 21 V dc and 36 V dc
The power supplies are installed in the rear of the chassis and are hot pluggable. The Cisco ASR 1002-X
Router supports up to 588 W input power from an infrastructure standpoint (cooling capacity, midplane, and
power distribution), but the initial power supply development limit is up to 470 W output (AC and DC input).
Cisco ASR 1000 Series Router Hardware Installation Guide
322
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
