Cisco ASR 1002 Hardware Installation Guide

Table 131: RJ-45 Management Ethernet Port Pinouts
DescriptionDirectionSignalPin
Bidirectional DataBiBi Data A+1
Bidirectional DataBi
Bi Data A–
2
Bidirectional DataBiBi Data B+3
Bidirectional DataBiBi Data C+4
Bidirectional DataBi
Bi Data C–
5
Bidirectional DataBi
Bi Data B–
6
Bidirectional DataBiBi Data D+7
Bidirectional DataBi
Bi Data D–
8
BITS/DTI Interface Port Signals and Pinouts
The following table lists the pinouts of the front panel BITS/DTI RJ45 port.
Table 132: BITS/DTI RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional (DTI)
Input/Bi (DTI)RX Ring1
Receive TIP
(T1/E1)/Bidirectional
(DTI)
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit Ring / unused
for DTI
OutputTX Ring5
Transmit TIP/ unused for
DTI
OutputTX TIP6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
640
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
BITS/DTI Interface Port Signals and Pinouts

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
