Cisco ASR 1002 Hardware Installation Guide

DescriptionComponent
Front and rear chassis rack-mount brackets that you
will attach to the chassis with the respective screws
Accessories Kit
You must order the Accessories Kit
separately if you order the Cisco ASR
1009-X Router or Cisco ASR 1006-X Router
chassis as a spare.
Note
Three sets of screws, one set for:
•
Front rack-mount brackets (use the black
screws)
•
Rear rack-mount brackets (use the package with
the 5 screws)
•
Cable-management brackets (use the package
with the 4 screws)
Two cable-management brackets with U-feature
design devices attached, with a different size for each
chassis.
1 RJ-45 to RJ-45 crossover cable
1 RJ-45 to DB-9 (female) adapter
One disposable wrist strapESD, Wrist Strap (disposable)
Regulatory Compliance and Safety Information for
the Cisco ASR 1000 Series Aggregation Services
Routers at http://www.cisco.com/c/en/us/td/docs/
routers/asr1000/rcsi/asr1rcsi.html.
Documentation
Power cord if an AC power supply was shipped.
There are none for the DC power supply units.
Optional Equipment
Most Cisco documentation is online or on the Cisco Documentation DVD. Documentation that ships with
your Cisco ASR 1000 Series Router includes the Regulatory Compliance and Safety Information for the
Cisco ASR 1000 Series Aggregation Services Routers document, and the Documentation Roadmap for
Cisco ASR 1000 Series, which provides links and information for the Cisco ASR 1000 Series Aggregation
Services Routers documentation.
Note
Cisco ASR 1000 Series Router Installation Checklist
To assist you with your installation and to provide a historical record of what was done by whom, photocopy
the Cisco ASR 1000 Series Router Installation Checklist shown in the following table. Use this to record
when each procedure or verification is completed. When the checklist is completed, place it in your site log
along with the other records for your new router.
Cisco ASR 1000 Series Router Hardware Installation Guide
136
Preparing Your Site for Installation
Cisco ASR 1000 Series Router Installation Checklist

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
