Cisco ASR 1002 Hardware Installation Guide

SUMMARY STEPS
1.
Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
2.
Remove the new Cisco ASR1000-ESP from its static shielding bag.
3.
Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its
printed circuit board components are upward.
4.
Align the left and right edges of the Cisco ASR1000-ESP printed circuit board between the Cisco
ASR1000-ESP slot guides.
5.
Gently slide the Cisco ASR1000-ESP all the way into its chassis slot until you feel the connectors seat
with the router midplane.
6.
Seat the Cisco ASR1000-ESP in the router midplane by tightening its captive installation screws with a
number 2 Phillips or a 3/16-inch flat-blade screwdriver.
DETAILED STEPS
Step 1
Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
Step 2
Remove the new Cisco ASR1000-ESP from its static shielding bag.
Step 3
Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its printed circuit
board components are upward.
Handle the Cisco ASR1000-ESP by the carrier edges and handle only; never touch the printed circuit board
components or connector pins.
Caution
Step 4
Align the left and right edges of the Cisco ASR1000-ESP printed circuit board between the Cisco ASR1000-ESP slot
guides.
Step 5
Gently slide the Cisco ASR1000-ESP all the way into its chassis slot until you feel the connectors seat with the router
midplane.
Step 6
Seat the Cisco ASR1000-ESP in the router midplane by tightening its captive installation screws with a number 2 Phillips
or a 3/16-inch flat-blade screwdriver.
What to Do Next
This completes the procedure for replacing the Cisco ASR1000-ESP in the Cisco ASR 1000 Series Router.
Removing and Replacing Cisco ASR 1000 Series Router SPAs
and SPA Interface Processors
This section contains the following topics:
For detailed information about SIP and SPA software commands such as activating and deactivating SIPs,
prepare for online insertion and removal of SPAs, and activate and deactivate configuration examples,
see Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Hardware Installation Guide .
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
533
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Router SPAs and SPA Interface Processors

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
