The Cisco ASR 1013 Router modular chassis supports redundant power entry modules (PEMs). At least one
PEM in each 1+1 redundant power supply zone must be functioning to power the zone and both zones must
be functional. In the event of a single fan failure, the remaining fans are sufficient to cool the entire chassis
although fan speed may have to be increased.
The Cisco ASR 1013 Router system is configured in a dual zone 1+1 power supply configuration. For ASR
1013 router power consumption specifications, see the “Cisco ASR 1013 Router Specifications” section on
page A-14 .
The following items list the maximum input and output of the system power consumption for the two power
zones in the Cisco ASR 1013 Router:
•
Maximum input (DC): 4,200W
• Maximum input (AC – High Line): 4,000 W
• Maximum output (DC and AC – High Line): 3,390 W
At least one power supply in each of the two power supply zones must be powered on before the software
boots up. This prevents the route processor from detecting a power supply failure in a zone that is not
being used to power the active route processor. If you plan to connect the four power supplies to two
independent circuits for redundancy, you must ensure that a power supply from each power supply zone
is connected to each circuit. PS0 and PS1 are in power supply zone 0, and PS2 and PS3 are in power
supply zone 1. In this scenario, for example, PS0 and PS2 can be connected to one circuit and PS1 and
PS3 can be connected to the other circuit. Alternatively, PS0 and PS3 can be connected to one circuit and
PS1 and PS2 can be connected to the other circuit.
Note
Detailed instructions for removing and replacing the Cisco ASR 1000 Series AC and DC power supplies
are in the “Removing and Replacing the Cisco ASR 1013 Router Power Supplies” section on page 14-93
.
Note
Connecting AC Input Power to Cisco ASR 1013 Router
Follow these steps to connect an AC-input power supply to the Cisco 1013 chassis:
SUMMARY STEPS
1.
At the rear of the chassis, check that the power switch on the power supply is in the Standby position.
2.
Plug the power cable into the inlet.
3.
Plug the AC power supply cable into the AC power source.
Cisco ASR 1000 Series Router Hardware Installation Guide
395
Cisco ASR 1013 Router Overview and Installation
Connecting AC Input Power to Cisco ASR 1013 Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
