DescriptionDirectionSignalPin
——
N/C7,8
Cisco ASR 1002-X Router BITS Port Signals and Pinouts
The following table lists the pinout of the front panel Building Integrated Timing Supply (BITS) RJ45 port
on the Cisco ASR 1002-X Router.
Table 115: BITS RJ-45 Interface Pinouts for Cisco ASR 1002-X Router
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive TIP (T1/E1)InputRX TIP2
Not used
—
N/C3, 4
Transmit RingOutputTX Ring5
Transmit TIP (T1/E1)OutputTX TIP6
——
N/C7,8
Cisco ASR 1002-X Router BNC GPS Ports
The following table describes the BNC GPS ports on the Cisco ASR 1002-X.
Table 116: GPS Port Pinout
1PPS (input and output)10 Mhz (input and output)Signal Attribute
Input—Pulse shape
Output—Pulse shape
Input—Sine wave
Output—Square wave
Waveform
Input— > 2.4 volts TTL
compatible
Output— > 2.4 volts TTL
compatible
Input— > 1.7 volt p-p(+8 to +10
dBm)
Output— > 2.4 volts TTL
compatible
Amplitude
50 ohms50 ohmsImpedance
26 microseconds50% duty cyclePulse Width
Cisco ASR 1000 Series Router Hardware Installation Guide
629
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002-X Router BITS Port Signals and Pinouts

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
