Table 79: Cisco ASR 1013 Router Dimensions and Weight
DimensionsCisco ASR 1013
22 in. (558.8cm) (including cable-management
brackets and power supply handles).
Depth
22.8 in. (579.1cm) - 13RU rack-mount per EIA
RS-310 standard
Height
17.2 in. (437.4 cm)Width
•
184.0 lbs (83.46 kg) (with redundant AC power
supply, SPA and route processor and SIP blank
covers, two Cisco ASR 1000 Series embedded
services processors (Cisco ASR1000-ESP40),
two Cisco ASR 1000 Series RP2s
(ASR1000-RP2), six Cisco ASR 1000 Series
40 Gbps SIPs (ASR1000-SIP40), and no SPAs).
Using Cisco ASR1000-ESP100 instead of
Cisco ASR1000-ESP40 adds 2.1 lbs to the
total weight of the router.
Note
•
Total weight with estimated superslot weight
with:
◦
A
C power supplies —202 pounds (91.6256
kg)
◦ DC power supplies—208.60 pounds
(94.6193 kg)
Weight
Guidelines for Equipment Rack Installation
The chassis should already be in the area where you will install it. If you have not determined where to install
your chassis, see the “Cisco ASR 1000 Series Routers Component Overview” section on page 2-1 for
information about site considerations.
When installing the Cisco ASR 1013 Router, consider the following items:
•
The Cisco ASR 1013 Router requires at least 3 inches (7.62 cm) of clearance at the inlet and exhaust
vents (the front and top/rear sides of the chassis).
•
The Cisco ASR 1013 Router should be installed off the floor. Dust that accumulates on the floor is drawn
into the interior of the router by the cooling fans. Excessive dust inside the router can cause
overtemperature conditions and component failures.
Cisco ASR 1000 Series Router Hardware Installation Guide
373
Cisco ASR 1013 Router Overview and Installation
Guidelines for Equipment Rack Installation

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
