Cisco ASR 1002 Hardware Installation Guide

Cisco Embedded ASR1000-SIP10 and SPAs for the Cisco ASR 1001 Router Description
The Cisco embedded ASR1000-SIP10 is built into the Cisco ASR 1001 Router. The Cisco embedded
ASR1000-SIP10 provides the physical and electrical termination for up to three SPAs, built-in 4xGE SPA,
one half-height SPA bay, and one integrated daughter card (system configurable).
The Cisco embedded ASR1000-SIP10 interface, like the Cisco ASR 1006 Router and Cisco ASR 1004 Router,
supports all Cisco embedded ASR1000-SIP10 functions and services. However, the Cisco embedded
ASR1000-SIP10 differs in the following areas:
•
Functions as the base board for Cisco embedded ASR1000-RP1
•
Is not a field-replaceable unit (FRU) and does not support online insertion and removal (OIR).
Only the shared port adapter (SPA) on the Cisco embedded ASR1000-SIP10 in SPA Bay 1 of the Cisco
ASR 1001 Router supports OIR.
Note
The Cisco ASR 1001 Router embedded ASR1000-RP1 also provides the circuitry for the built-in 4xGE SPA.
Table 82: Built-In SPA LEDs , on page 421 describes the built-in SPA LEDs.
Table 82: Built-In SPA LEDs
DescriptionColorFunction
Indicates that the port is enabled by
software, but there is a problem with the
Ethernet link.
AmberGE SFP STATUS (one per port)
Indicates that the port is enabled by
software and there is a valid Ethernet link.
Green
Cisco ASR 1001 Router Integrated Daughter Card Description
The ASR 1001 Router supports different flexible integrated daughter cards with their own LEDs. Four of
these integrated daughter cards are based on SPAs and use the same external I/O ports as those SPAs. One
of the integrated daughter cards supports a single hard-disk-drive for other applications.
Table 83: Built-In SPA LEDs, on page 421 describes the built-in SPA LEDs.
Table 83: Built-In SPA LEDs
DescriptionColorFunction
Amber indicates the port is enabled by
software, but there is a problem with a port
connection.
AmberDaughter Card Port Status (one per port)
Green indicates the port is enabled by
software and operational.
Green
Cisco ASR 1000 Series Router Hardware Installation Guide
421
Cisco ASR 1001 Router Overview and Installation
Cisco ASR 1001 Router Components

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
