Cisco ASR 1002 Hardware Installation Guide

Table 75: +24 VDC Output Voltage Alarm Threshold Ranges
MaximumMinimumOutput
12.8-13.8 V10.0-11.2 V12 V
None
2.6 – 3.0 V
3.3 V
• Temperature—If a fan fails, the power supply meets the functional requirements specified in above
table. The calculated MTBF does not apply above 55°C with less than two fans. However, all the
component stress remains within the manufacturer’s specified rating.
• Thermal shutdown—The +24 VDC power supply shuts down to protect its components due to excessive
internal temperature. The +24 VDC power supply then automatically restarts after the internal temperature
returns to a safe operating level.
Power Cords Supported by the Cisco ASR 1002-X Router
The following table lists the power cords that are supported by the Cisco ASR 1002-X Router.
Table 76: Power Cords Supported by the Cisco ASR 1002-X Router
DescriptionPower Cord Item Number
Power Cord, 110 V, Right AngleCAB-AC-RA
Plug, Power Cord, Australia, 10 A, Right AngleCAB-ACA-RA
Power Cord, Brazil, Right Angle, 10 ACAB-ACB10A-RA
Power Cord, Brazil, Right Angle, 16 ACAB-ACB16A-RA
Power Cord, China, Right AngleCAB-ACC-RA
Power Cord, Europe, Right AngleCAB-ACE-RA
Power Cord, Italy, Right AngleCAB-ACI-RA
Power Cord, Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord, UK, Right AngleCAB-ACU-RA
Power Cord, India, Right AngleCAB-IND-RA
Power Cord, Japan, Right AngleCAB-JPN-RA
Cisco ASR 1000 Series Router Hardware Installation Guide
330
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
