Before you mount the Cisco ASR 1002-F Router in a rack, make certain you understand which rack-mount
bracket ear holes to use when positioning the chassis in the rack. As a result of using the designated ear
holes on the rack-mount bracket, the cable-management bracket installation will be made easier.
Caution
Installing the Cisco ASR 1002-F Router in a Rack
After installing the rack-mount brackets on the chassis, you mount the chassis by securing the rack-mount
brackets to two posts or mounting strips in the rack using the screws provided.
Because the rack-mount brackets support the weight of the entire chassis, be sure to use all the screws to
fasten the rack-mount brackets to the rack posts.
Note
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions
to ensure that the system remains stable.
Danger
The following guidelines are provided to ensure your safety:
•
This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
•
When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack
.
•
If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack. Statement 1006
We recommend that you allow at least 1 or 2 inches (2.54 or 5.08 cm) of vertical clearance between the router
and any equipment directly above and below it.
To install the chassis in the rack, perform the following steps:
Step 1
On the chassis, ensure that all screws on the installed components are securely tightened.
Step 2
Make sure that your path to the rack is unobstructed. If the rack is on wheels, ensure that the brakes are engaged or that
the rack is otherwise stabilized. For chassis rack-mount installation types, see the “Two-Post Rack Installation” or the
“Four-Post Rack Installation.”
Step 3
(Optional) Install a shelf in the rack to support Cisco ASR 1002-F Router. If you use a shelf, this will help support the
chassis while you secure it to the rack.
Step 4
Lift the chassis into position between the rack posts.
Step 5
Align the mounting bracket ear holes with the rack post holes to attach the chassis to the rack.
If you are using a shelf, raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the
brackets, but continue to support the chassis.
Note
Step 6
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Step 7
Hold the chassis in position against the mounting rails in the equipment rack and follow these steps:
Cisco ASR 1000 Series Router Hardware Installation Guide
296
Cisco ASR 1002-F Router Overview and Installation
Installing the Cisco ASR 1002-F Router in a Rack

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
