Cisco ASR 1002 Hardware Installation Guide

DC power supply captive
screw
7Fan1
DC power supply handle8DB-25 alarm connector*2
Terminal block and
plastic cover single screw
9Tie-wrap tab3
On/Off (|/O) circuit
breaker switch
10DC power supply
terminal block and plastic
cover
4
Terminal block and
plastic cover slot tab
11Ground symbol5
Power supply LEDs12DC power supply ground
studs
6
The following table describes the power supply LEDs and connectors on the rear of the chassis.
Table 33: Cisco ASR 1013 Router – 48 VDC Power Supply LEDs
DescriptionColorLEDLED Label
LED illuminates green to signal
that the –48 VDC power supply
input voltage is greater
than–43.5VDC at turn-on and
remains green down to
–39VDC.
GreenA bi-color LED indicates input
voltage
INPUT OK
The LED illuminates amber
when the input voltage (falls
below –39VDC) and indicates
that there is still a voltage
present (voltage on the terminal
block). The LED remains amber
and is active to around 25 V
+/-5 V. The LED is not
illuminated if the input is below
–15 V input.
Amber
The LED illuminates s green
when all fans are operational.
GreenA bi-color LED indicates power
supply fan status
FAN OK
The LED illuminates red when
a fan failure is detected.
Red
Cisco ASR 1000 Series Router Hardware Installation Guide
81
Cisco ASR 1000 Series Routers Component Overview
–48 VDC Power Supply LEDs and Connectors for Cisco ASR 1013

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
