Cisco ASR 1002 Hardware Installation Guide

SUMMARY STEPS
1.
On the chassis, ensure that all screw fasteners on the installed components are securely tightened.
2.
Make sure that your path to the rack is unobstructed. If the rack is on wheels, ensure that the brakes are
engaged or that the rack is otherwise stabilized. See the next sections on the types of racks you can use to
install the chassis.
3.
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you use a shelf, this will
help support the chassis while you secure it to the rack.
4.
With two people, lift the chassis into position between the rack posts.
5.
Align the mounting bracket holes with the rack post holes and attach the chassis to the rack.
6.
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
7.
Hold the chassis in position against the mounting rails and follow these steps:
8.
Tighten all screws on each side to secure the chassis to the equipment rack.
DETAILED STEPS
Step 1
On the chassis, ensure that all screw fasteners on the installed components are securely tightened.
Step 2
Make sure that your path to the rack is unobstructed. If the rack is on wheels, ensure that the brakes are engaged or that
the rack is otherwise stabilized. See the next sections on the types of racks you can use to install the chassis.
Step 3
(Optional) Install a shelf in the rack to support the Cisco ASR 1004 Router. If you use a shelf, this will help support the
chassis while you secure it to the rack.
Step 4
With two people, lift the chassis into position between the rack posts.
Step 5
Align the mounting bracket holes with the rack post holes and attach the chassis to the rack.
If you are using a shelf then raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the
brackets, but continue to support the chassis.
Note
Step 6
Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Step 7
Hold the chassis in position against the mounting rails and follow these steps:
a) The Cisco ASR 1004 rack-mount ears contain 8 ear holes. Insert the bottom screw into the third hole up from the
bottom of the rack-mount ear and use a hand-held screwdriver to tighten the screw to the rack rail.
In the next step, insert the top screw diagonally from the bottom screw that you just attached.This helps with
keeping the chassis in place.
Note
b) Insert the top screw into the third hole down from the top of the rack-mount ear and tighten the screw to the rack rail.
c) Insert a screw in the middle of the rack-mount bracket on both sides of the chassis.
d) Repeat these steps for the other side of the chassis.
As a result of using the specified rack-mount bracket ear holes, the cable-management bracket can be easily
attached to the rack-mount bracket when the chassis is in the rack.
Note
Step 8
Tighten all screws on each side to secure the chassis to the equipment rack.
What to Do Next
You can install your Cisco ASR 1004 chassis on a two-post rack or a four-post rack. For instructions, see the
Two-Post Rack Installation, on page 197 or the Four-Post Rack Installation, on page 199.
Cisco ASR 1000 Series Router Hardware Installation Guide
196
Cisco ASR 1004 Router Overview and Installation
Installing the Cisco ASR 1004 Router in a Rack

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
