Do not install wire into the terminal block that has not had its insulation removed.Caution
Figure 109: Cisco ASR 1002 Router +24 VDC Power Supply Lead Wire Inserted into Terminal Block
Copper wire2Lead wire insulation1
The follwing image shows the lead wire fully inserted.
Figure 110: Cisco ASR 1002 Router +24 VDC Power Supply Lead Wire Fully Inserted
——
Fully-inserted lead wire1
Cisco ASR 1000 Series Router Hardware Installation Guide
268
Cisco ASR 1002 Router Overview and Installation
Connecting Cisco 24 VDC Power Supply
