Cisco ASR 1002 Hardware Installation Guide

Captive installation screw6Chassis ESD socket1
DC power supply slot 1
label
7DC power supply slot 0
label
2
Ground lead8DC power supply
Standby/On (|) switch
3
Positive lead9DC power supply LEDs4
Negative lead10Fan5
The following table defines the Cisco ASR 1002-F Router DC power supply LEDs on the Cisco ASR 1002-F
Router.
Table 64: Cisco ASR 1002-F Router DC Power Supply LEDs
DescriptionColorLEDLED Label
The DC power supply input
voltage is greater than 43.5
VDC at turn-on and remains
green down to 39 VDC.
GreenPower supply activityINPUT OK
The power supply turns off due
to low input voltage (falls below
39VDC) and indicates that there
is still a hazard present (voltage
on the terminal block). The
LED remains amber and is
active to around 20 V +/-5 V.
Amber
The input is below 15VOff
All fans are operational.GreenPower supply fan status activityFAN OK
A fan failure is detected.Red
The DC output is out of the
specified range. When you turn
the power supply on, the red
LED illuminates for two to
three seconds to test LED
operation before going off.
RedPower supply activityOUTPUT FAIL
The DC output voltage are
within the normal operating
range.
Off
Cisco ASR 1000 Series Router Hardware Installation Guide
285
Cisco ASR 1002-F Router Overview and Installation
Power Supplies in the Cisco ASR 1002-F Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
