Cisco ASR 1002 Hardware Installation Guide

Power supply tabs8Negative (-) lead3
+27 VDC INPUT label9Ground (GND) lead4
——
Power supply LEDs5
The following table shows the definitions of the Cisco ASR 1002-X Router +24 VDC power supply LEDs.
Table 73: Cisco ASR 1002-X Router +24 VDC Power Supply LEDs
DescriptionColorLEDLED Label
When the LED is off, it signals
that the +24 VDC output
voltage is within the normal
operating range. Output voltage
between the minimum limit and
maximum limit will not create
an output fail alarm, but output
voltages below the minimum
limit or above the maximum
limit will create an Output Fail
alarm.
When you turn the power
supply on, LED turns red for
two to three seconds to test the
LED operation before going off.
RedPower supply activityOUTPUT FAIL
The LED turns green to signal
that voltage is > or = to 20 VDC
at turn-on and the voltage
reduces to 19.0VDC (+/- 0.5 V
tolerance).
GreenA bicolor LED indicates the
presence of input voltage
INPUT OK
The LED turns to amber when
the input voltage is active and
is reduced to 16.0 VDC and
indicates that a voltage on the
terminal block is still present.
The LED remains amber and is
active until around 10 V. The
LED should be OFF below 15.8
VDC.
Amber
The LED turns to green when
all fans are operational.
GreenA bicolor LED indicates the
power supply fan status
FAN OK
The LED turns to red when a
fan failure is detected.
Red
Cisco ASR 1000 Series Router Hardware Installation Guide
328
Cisco ASR 1002-X Router Overview and Installation
Power Supplies in the Cisco ASR 1002-X Router

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
