SUMMARY STEPS
1.
With a wrist strap on, remove the power supplies from the chassis.
2.
After the power supplies are removed, remove the chassis top cover by performing the following steps:
3.
Position the chassis so that you are facing the front of the chassis to remove the DIMM.
4.
Locate the DIMM on the ASR 1001 Router. See Figure 14-20, callout 1.
5.
Pull down the lever on the DIMM socket to release the corresponding DIMM from the socket. See the
following figure.
6.
When one end of the DIMM is released from the socket, grasp each end of the DIMM with your thumb
and forefinger and pull the DIMM completely out of the socket. Handle only the edges of the DIMM;
avoid touching the memory module, pins, and the metal traces (the metal fingers along the connector edge
of the DIMM) along the socket edge.
7.
Place the DIMM in an antistatic bag to protect it from ESD damage.
8.
Repeat Step 8 through Step 10 for the remaining DIMMs if required for your upgrade.
DETAILED STEPS
Step 1
With a wrist strap on, remove the power supplies from the chassis.
The chassis cover cannot be removed until the power supplies are removed from the chassis.Note
For instructions about how to remove the AC and DC power supplies from the Cisco ASR 1001 Router, see:
xref Removing AC Power Supply from the Cisco ASR 1001 Router
xref Removing DC Input Power from the Cisco ASR 1001 Router
Step 2
After the power supplies are removed, remove the chassis top cover by performing the following steps:
a) Loosen all top surface screws on the chassis cover, as shown in the following figure, callout 3.
Cisco ASR 1000 Series Router Hardware Installation Guide
509
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR 1001 Router DIMM Memory Modules
