Cisco ASR 1002 Hardware Installation Guide

New Behavior
From Cisco IOS XE Release 2.3.0 onwards, an additional message is displayed on the auxiliary port and on
the Cisco IOS console port, providing information whether the eUSB device currently used is correct. For
Cisco ASR 1001 Router, this change for eUSB compatibility has been implemented from Cisco IOS XE
Release 2.4.0S onwards. The recommended eUSB devices with the minimum memory capacity for the RP
types compatible are:
Table 94: Matrix for eUSB Memory Capacity Support and Route Processor on ASR 1000 Routers
eUSB Capacity (Gigabytes)Router Type
81RU-RP
82RU-RP
14RU-RP1
16RU-RP1
1 (subject to change)13RI-RP1
24RU-RP2
26RU-RP2
213RU-RP2
When the system is started, Cisco IOS Software detects the capacity of the eUSB device currently used on
the system. If the eUSB device matches the minimum value of the eUSB capacity as specified above then no
messages are displayed at the Cisco IOS console.
However, an informational message is displayed at the auxiliary port. For example, on a 6RU system, at the
auxiliary port, the following message appears if the eUSB is valid:
....
Checking eUSB capacity information for 6RU:ASR1000-RP1 ... 1003520 KBytes [ OK ]
..
However, when an invalid eUSB device is found, the following messages are displayed at the Cisco IOS
Console:
...
%IOSXEBOOT-4-EUSB_PROVISIONING: (rp/0): Unsupported low capacity eUSB detected in 2RU
board
...
The following message is displayed at the auxiliary port:
...
Checking eUSB capacity information for 2RU:ASR1000-RP-2RU ...
The capacity of the installed eUSB device is insufficient.
It is 1003520 KBytes. The recommended capacity is 8 GByte(s).
%IOSXEBOOT-4-EUSB_PROVISIONING: (rp/0): Unsupported low capacity eUSB detected in 2RU board
...
Cisco ASR 1000 Series Router Hardware Installation Guide
530
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Minimum Requirements of eUSB Devices Supported on Cisco ASR 1000 Series Routers

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
