DETAILED STEPS
Step 1
There are two power supplies installed. At the rear of the chassis, check whether the power switch on the chassis is in
the Standby position.
Do not install the Cisco ASR 1001 Router power supplies without the top cover on the Cisco ASR 1001
chassis.
Warning
The following figure shows the Cisco ASR 1001 Router AC power supply standby switch.
Figure 301: Cisco ASR 1001 Router AC Power Supply Standby Switch
Cisco ASR 1001 Router AC power supply Standby switch.
This switch does not disconnect power from the power
source.
1
