Cisco ASR 1002 Hardware Installation Guide

Table 17: Cisco ASR 1006 Router AC Power Supply LEDs
DescriptionColorLEDLED Label
LED illuminates green to
signal that the AC power
supply input voltage is
greater than 85 V.
GreenPower supply activityINPUT OK
If LED is not illuminated,
then the AC input voltage
is less than 70 V or the
power supply is turned
off. For an AC input
voltage between 70 V and
85V, the INPUT OK LED
can be either on, off, or
flashing
None
LED illuminates green
when all fans are
operational.
GreenBi-color LED indicates
fan status
FAN OK
The LED illuminates red
when a fan failure is
detected.
Red
LED is red and turned off
to signal that the -48 VDC
output voltages are within
the normal operating
range; output voltage
between the minimum
and maximum limits will
not create an output fail
alarm, and output
voltages below the
minimum or above the
maximum will create an
output fail alarm.
When you turn the power
supply on, the red LED is
illuminated for two to
three seconds for testing
LED operation before
going off.
RedPower supply activityOUTPUT FAIL
Cisco ASR 1000 Series Router Hardware Installation Guide
55
Cisco ASR 1000 Series Routers Component Overview
AC Power Supply LEDs and Connector for Cisco ASR 1006

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
