164
Compulite
Chapter 12
System options
The system options are used to configure basic Dlite default behaviour.
The main
System Options screen displays the operating software version and the amount of free
memory in KBytes.
Choosing and configuring an option in the
System Option screen immediately operates the option
without storing or tapping
OK.
Behavior
Press SETUP > SYSTEM OPTIONS > BEHAVIOR
Feature Setting Description
Playback Stomp
for LTP parameters
ON When all parameters output from a playback are overridden,
the playback is turned off.
Example: Playback 1 is active and outputs spots 1 through 4
set to blue and focussed on the drum riser. If you now turn on
playback 2, which outputs the same moving lights running
position and color effects, playback 1 is released and no longer
active. If you stop playback 2, the parameters go to their home
levels or tracking.
OFF The system never stomps (overrides) the previously active
playback. Referring to the example above, if you stop playback
2, the moving lights revert to the output from playback 1.
PB Jump off Zero
ON Moving playback sliders off their bottom end stop (0) automat-
ically turns on the playback. There is no need to press the
SELECT key.
OFF Moving playback sliders off their bottom end stop (0) does not
automatically turn on the playback. You must press the
SELECT
key to turn on the playback.
CrossFader as LTP
ON Set the crossfader to the same priority as the playbacks.
OFF The crossfader is a lower priority and will always be over-
ridden by output from the playbacks.
Paging on Faders
ON Allows paging faders in wide and 2 preset modes.
OFF Does not allow paging faders in wide and 2 preset modes.
Faders as Editor
ON For wide mode only!
Dimmer levels set by the faders are active in the editor.
OFF Dimmer levels set by the faders are not active in the editor.
To Next Page
