Sound-to-Light
Sound-to-Light operates playbacks automatically. Playbacks loaded with scenes flash on the beat.
Chasers on playbacks advance one step on the beat. The wheels control 3 sound-to-light
parameters:
Wheel 1 - F(requency), measured in Hertz.
Wheel 2 - Q, how much of the band affects the range of frequencies.
Wheel 3 - T(hreshold), the level at which the fade or flash is triggered.
To connect a sound source
Plug a sound source into the audio 3 pin XLR connector on Dlite’s back panel.
Note: Input voltage must be between 1.5 - 30 volts peak to peak. For optimal perfor-
mance use 3.5 - 10 volts peak to peak inputs.
To enable sound-to-light operation
1 Press
SETUP.
2 Tap
SYSTEM OPTIONS.
3 Tap
I/O
4 Tap SOUND-TO-LIGHT.
5 Tap
ENABLE.
ENABLE appears on a dark field.
Hold Mode
Put chases into manual
mode and freeze effects
NOTE-ON 58 – Change system to Hold mode ON/OFF.
Use
NOTE-ON 0-19 to select playbacks 1-20 accordingly.
Direction Change
NOTE-ON 57 – Change system into Direction mode ON/OFF.
Use
NOTE-ON 0-19 to select playbacks 1-20 accordingly.
Solo Mode
NOTE-ON 56 – Change system into Solo mode ON/OFF.
Use
NOTE-ON 0-19 to select playbacks for Fade-Solo.
Use
NOTE-ON 20-39 to select playbacks for Flash-Solo.
Crossfader control
NOTE-ON 53 - Go command (fade to next cue).
NOTE-ON 54 - Back (fade to previous cue).
Console Rate/GM
Use CONTROL-CHANGE MESSAGE 7 (channel volume) + value
0-127, to control system Dimmer/Rate GM.
BO key
NOTE-ON 60 – Change system BO key status.
All Off Command
NOTE-ON 55 – Turn off all running playbacks.
Function Description
