157
DLITE
Advanced Programming
The button now has a dark field.
4 Continue and store the lighting object using the usual procedures.
5 The system reverts to the default store option as configured in the
Setup menu.
To use the Update Source option
Dlite’s current output is:
Update scene 2 (on playback 2) by changing the pan/tilt values to 60/60.
Update scene 3 (on playback 5) by changing the cyan value to 50.
1 Select spot 10.
2 Set the pan/tilt values to 60/60.
3 Set the cyan value to 50.
4 Press
UPDATE.
The store options are displayed.
If
UPDATE SOURCE is the default, press ENTER now to complete the command.
If
UPDATE SOURCE is not the default, continue with steps 5 and 6/
5 Tap
UPDATE SOURCE.
6 Press
ENTER.
Cues are updated with the editor levels for the parameters active in each source cue.
The updated output is:
Note: The Update Source option is valid for scenes and cues. Chase steps are ignored.
Using one- parameter scenes on playbacks
One- parameter scenes are scenes that contain just one parameter. When loaded on a playback, they
can be used to fade the parameter levels during live operation.
The parameter fades proportionately from zr to the stored value. Example: Store a scene with the
iris set to 80%; when the playback is at FL the iris is at 80%. To allow the full level range, set the
parameter to full before storing the scene.
Playback Device Scene Spot Dimmer Pan/Tilt Cyan
Playback 2
2 10 Full 50/50
Playback 5
310 80
Playback Device Scene Spot Dimmer Pan/Tilt Cyan
Playback 2
2 10 Full 60/60
Playback 5
310 50
