167
DLITE
System Setup and Operations
For more information on SMPTE, MIDI, and Sound-to-Light, see “Automated Playback” page 171.
For more information on master/slave configuration, see “Master/Slave Tracking Back Up”
page 177.
Feature Sub Menus Description
ETHERNET Enable VC
Enable / disable DMX transmission over Ethernet.
ATTENTION! If the Ethernet cable is not connected
make sure that VC transmission is disabled.
Enable
Art-Net
Enable / disable Art-Net transmission over Ethernet.
Network
Settings
Use the wheels to:
• Set the console’s IP address.
• Set the console’s Subnet mask.
• Set the VC.
Note: Use z (dot key) to jump from byte to byte.
CONNECT TO
PC
See “Connecting to a PC” on page 169.
ATTENTION! If the modem cable is not connected
make sure that Connect to PC is disabled.
SMPTE Enable
Enable SMPTE communication.
Start Clock
Restart the SMPTE clock where it stopped.
Stop Clock
Stop SMPTE clock.
Restart
Clock
Restart clock from 0:0:0:0.
Teach
SMPTE
Teach SMPTE for automatic playback.
MIDI Enable MIDI
Load
Defaults
SOUND TO
LIGHT
Enable
Enabled for sound to light operation.
SLAVE
none Enabled - the console is working as a backup console, tracking
the main (or master) console. When enabled the button has a
dark field.
MASTER
none Enabled - the console is working as a master console with a
second console working as a backup console. When enabled
the button has a dark field.
