Option Name Description
[171] Target Position Reached The target position is reached. This option
is only effective when parameter 37-00
Application Mode is set to [2] Position
Control.
[172] Position Control Fault A fault occurred in the positioning
process. Refer to parameter 37-18 Pos.
Ctrl Fault Reason for details about the
fault. This option is only effective when
parameter 37-00 Application Mode is set
to [2] Position Control.
[193] Sleep Mode The drive/system has entered sleep mode.
See parameter group 22-4* Sleep Mode.
[194] Broken Belt Function A broken belt condition has been
detected. See parameter group 22-4*
Sleep Mode.
5-31 Terminal 29 Digital Output
Default value: [0] No operation Parameter type: Option
Setup: All setups Conversion index: –
Data type: Uint8 Change during operation: True
Select the function to control the digital output.
Option Name Description
[0] No operation Default for all digital outputs and relay
outputs.
[1] Control Ready The control card is ready.
[2] Drive ready The drive is ready for operation and
applies a supply signal on the control
board.
[3] Drive rdy/rem ctrl The drive is ready for operation and is in
auto-on mode.
[4] Stand-by/no warning Ready for operation. No start or stop
command is given (start/disable). No
warnings are active.
[5] Running The motor is running and shaft torque is
present.
[6] Running/no warning The motor is running and there are no
warnings.
124 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
