Programming Guide | VLT® AutomationDrive FC 360
Option Name Description
[7] Run in range/no warn The motor is running within the
programmed current and speed ranges
set in parameter 4-50 Warning Current
Low to parameter 4-51 Warning Current
High. There are no warnings.
[8] Run on ref/no warn The motor runs at reference speed. No
warnings.
[9] Alarm An alarm activates the output.
[10] Alarm or warning An alarm or a warning activates the
output.
[11] At torque limit The torque limit set in parameter 4-16
Torque Limit Motor Mode, or parameter
4-17 Torque Limit Generator Mode has
been exceeded.
[12] Out of current range The motor current is outside the range set
in parameter 4-18 Current Limit.
[13] Below current, low The motor current is lower than set in
parameter 4-50 Warning Current Low.
[14] Above current, high The motor current is higher than set in
parameter 4-51 Warning Current High.
[15] Out of frequency range Output frequency is outside the frequency
range.
[16] Below frequency, low The output speed is lower than the setting
in parameter 4-40 Warning Freq. Low.
[17] Above frequency, high The output speed is higher than the
setting in parameter 4-41 Warning Freq.
High.
[18] Out of feedb. range The feedback is outside the range set in
parameter 4-56 Warning Feedback Low
and parameter 4-57 Warning Feedback
High.
[19] Below feedback, low The feedback is below the limit set in
parameter 4-56 Warning Feedback Low.
[20] Above feedback, high The feedback is above the limit set in
parameter 4-57 Warning Feedback High.
[21] Thermal warning The thermal warning turns on when the
temperature exceeds the limit in the
motor, the drive, the brake resistor, or the
thermistor.
[22] Ready, no thermal warning The drive is ready for operation, and there
is no overtemperature warning.
Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507 | 125
