Option Name Description
[30] Brake fault (IGBT) The output is logic 1 when the brake IGBT
is short-circuited. Use this function to
protect the drive if there is a fault on the
brake modules. Use the output/relay to
cut out the mains voltage from the drive.
[31] Relay 123 The relay is activated when [0] Control
Word is selected in parameter group 8-**
Communications and Options.
[32] Mech brake ctrl Enable control of an external mechanical
brake. See parameter group 2-2*
Mechanical Brake for more details.
[36] Control word bit 11
[37] Control word bit 12
[40] Out of ref range This option is active when the actual
speed is outside the settings in parameter
4-54 Warning Reference Low to parameter
4-55 Warning Reference High.
[41] Below reference, low This option is active when the actual
speed is below the speed reference
setting.
[42] Above ref, high This option is active when the actual
speed is above the speed reference
setting.
[45] Bus ctrl. Control output via fieldbus. The state of
the output is set in parameter 5-90 Digital
& Relay Bus Control. The output state is
retained in the event of fieldbus timeout.
[46] Bus control, timeout: On Control output via fieldbus. The state of
the output is set in parameter 5-90 Digital
& Relay Bus Control. When bus timeout
occurs, the output state is set high (On).
[47] Bus control, timeout: Off
[56] Heat sink cleaning warning, high
[60] Comparator 0 See parameter group 13-1* Comparators.
If comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators.
If comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators.
If comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
152 | Danfoss A/S © 2024.01 AU275649936274en-001401 / 130R0507
Programming Guide | VLT® AutomationDrive FC 360
