SAFETY AND IMPORTANT WARNING ITEMS
S-16
5.2 Laser Safety Label
• A laser safety labels is attached to the outside of the machine as shown below.
5.3 Laser Caution Label
• A laser caution label is attached to the inside of the machine as shown below.
5.4 Precautions For Handling The Laser Equipment
• When laser protective goggles are to be used, select ones with a lens conforming to the
above specifications.
• When a disassembly job needs to be performed in the laser beam path, such as when
working around the printerhead and PC Drum, be sure first to turn the copier OFF.
• If the job requires that the copier be left ON, take off your watch and ring and wear laser
protective goggles.
• A highly reflective tool can be dangerous if it is brought into the laser beam path. Use
utmost care when handling tools on the user’s premises.
4040P0C506DA
* Only for the U.S.A.
4040P0C503DA
To Next Page
